Quick Start Guide
5
5.1 Procedure
Follow this procedure:
1. Put a battery into the battery compartment.
2. Charge the battery for 4 hours before starting the camera for the first time, or until the
green battery condition LED glows continuously.
3. Insert a memory card into the card slot.
4. Push
to turn on the camera.
5. Aim the camera toward the object of interest.
6. Adjust the focus by rotating the focus ring.
Note It is very important to adjust the focus correctly. Incorrect focus adjustment af-
fects how the image modes Thermal MSX, Thermal, and Picture-in-picture work. It al-
so affects the temperature measurement.
7. Push the Save button (the trigger) to save an image.
8. Install FLIR Tools on your computer.
9. Start FLIR Tools.
10. Connect the camera to the computer using the USB cable.
11. Import the images into FLIR Tools and create a PDF report.
#T559845; r. AJ/37554/37554; en-US
10

Table of Contents

Other manuals for FLIR E60

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the FLIR E60 and is the answer not in the manual?

FLIR E60 Specifications

General IconGeneral
Resolution320 x 240 pixels
Thermal Sensitivity<0.05°C at 30°C
Field of View25° x 19°
Battery Life4 hours
Spatial Resolution1.36 mrad
Image Frequency60 Hz
MeterLinkYes
Laser PointerYes
Text AnnotationYes
Storage MediaSD card
Spectral Range7.5 – 13 µm
Temperature Range-20°C to +650°C
Display3.5" LCD touchscreen
FocusManual
Accuracy±2°C or ±2% of reading
Image ModesThermal, visual, MSX
Voice AnnotationYes
Battery TypeLi-Ion battery
Minimum Focus Distance0.4 m
Operating Temperature Range-15°C to +50°C
Storage Temperature Range-40°C to +70°C
ConnectivityWi-Fi, USB
Image StorageJPEG
