FLIR E60 User Manual

Recording video clips
20
20.1 General
You can record non-radiometric video clips in the following image modes:
• Thermal MSX.
• Thermal.
• Picture-in-picture.
• Digital camera.
The video clips can be played back in Microsoft Windows Media Player, but it will not be
possible to retrieve any temperature values from them.
20.2 Procedure: Recording a video clip
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Use the navigation pad to go to Recording mode.
3. Push the navigation pad.
4. Select Video and push the navigation pad.
5. Push the Save button to start the recording. A red icon at the top of the image blinks
during the recording.
6. Push the Save button again to stop the recording.
20.3 Procedure: Playing a video clip
Follow this procedure:
1. Push
to open the image archive.
2. Push the navigation pad up/down or left/right to select the video clip that you want to
play.
3. Push the navigation pad to open the video clip.
4. Push the navigation pad to display a toolbar.
5. On the toolbar, select Play and push the navigation pad.
#T559845; r. AJ/37554/37554; en-US
47

FLIR E60 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	<0.05°C at 30°C
Field of View	25° x 19°
Battery Life	4 hours
Spatial Resolution	1.36 mrad
Image Frequency	60 Hz
MeterLink	Yes
Laser Pointer	Yes
Text Annotation	Yes
Storage Media	SD card
Spectral Range	7.5 – 13 µm
Temperature Range	-20°C to +650°C
Display	3.5" LCD touchscreen
Focus	Manual
Accuracy	±2°C or ±2% of reading
Image Modes	Thermal, visual, MSX
Voice Annotation	Yes
Battery Type	Li-Ion battery
Minimum Focus Distance	0.4 m
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Connectivity	Wi-Fi, USB
Image Storage	JPEG
