FLIR E60 User Manual

Working with image modes
15
15.1 General
You can choose between different image modes when capturing an image.
15.2 Types of image modes
These are the image modes you can choose from:
Thermal MSX (Multi Spectral Dynamic Imaging):
Using this mode, the camera captures infrared im-
ages where the edges of the objects are en-
hanced. Note that the label for each fuse is clearly
legible.
Thermal: Using this mode, the camera captures
an ordinary infrared image.
Picture-in-picture: Using this mode, the camera
captures an infrared image frame that is displayed
on top of a digital photo.
Digital camera: Using this mode, the camera cap-
tures an ordinary digital photo.
#T559845; r. AJ/37554/37554; en-US
37

FLIR E60 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	<0.05°C at 30°C
Field of View	25° x 19°
Battery Life	4 hours
Spatial Resolution	1.36 mrad
Image Frequency	60 Hz
MeterLink	Yes
Laser Pointer	Yes
Text Annotation	Yes
Storage Media	SD card
Spectral Range	7.5 – 13 µm
Temperature Range	-20°C to +650°C
Display	3.5" LCD touchscreen
Focus	Manual
Accuracy	±2°C or ±2% of reading
Image Modes	Thermal, visual, MSX
Voice Annotation	Yes
Battery Type	Li-Ion battery
Minimum Focus Distance	0.4 m
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Connectivity	Wi-Fi, USB
Image Storage	JPEG
