Technical data23
USB
USB
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC / un-
compressed colorized video
USB, standard USB Mini-B: 2.0
USB, connector type
• USB-A connector
• USB Mini-B connector
Composite video
Video out Composite
Video, standard CVBS (ITU-R-BT.470 PAL/SMPTE 170M NTSC)
Video, connector type 4-pole 3.5 mm jack
Power system
Battery type Rechargeable Li ion battery
Battery voltage 3.7 V
Battery capacity
4.4 Ah, at +20°C to +25°C (+68°F to +77°F)
Battery operating time
Approx. 4 hours at +25°C (+77°F) ambient tem-
perature and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or
2-bay charger
Charging time
4 h to 90% capacity, charging status indicated by
LED's
Charging temperature 0°C to +45°C (+32°F to +113°F)
Power management Automatic shutdown and sleep mode (user
selectable)
AC operation AC adapter, 90–260 VAC input, 12 V output to
camera
Start-up time from sleep mode Instant on
Environmental data
Operating temperature range –15°C to +50°C (+5°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
to +40°C (+77°F to +104°F) / 2 cycles
EMC
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 B (Emission)
Magnetic fields EN 61 000-4-8, Test level 5 for continuous field
(severe industrial environment)
Encapsulation IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Drop 2 m (6.6 ft.)
Safety EN/UL/CSA/PSE 60950-1
Physical data
Camera weight, incl. battery 0.869 kg (1.91 lb.)
Camera size (L × W × H) 246 × 97 × 184 mm (9.7 × 3.8 × 7.2 in.)
Tripod mounting UNC ¼"-20 (adapter needed)
#T559845; r. AJ/37554/37554; en-US
