•Considercablelengthsandcablerouting.
Removingthekeypadmat
T ogainaccesstothemountingholelocations,thekeypadmatmustberemoved.
Note:T ohelppreventscratchingtheproduct,coverthetipofyourscrewdriverbladewith
asmallpieceofinsulationtape.
1.Usingathin,atbladedscrewdriverinsertthetipofthescrewdriverintothegapbetween
theedgeofthekeypadmatandthekeypadhousing.
2.Gentlyleverthekeypadmatawayfromthekeypadtoreleasethekeypadmat.
T akecarenottobendthekeypadmatduringremoval.
Flushmountingthekeypad
Flushmountingprovidesasleekinstallationwheretheproductanddashareush,withonly
thebuttonsandRotarycontrollerprotrudingfromthedash.Flushmountingrequiresthe
mountingsurfacetoberebated.
