FLIR M300C User Manual

Description
4
Joystickcontrolunit(JCU-2),availableseparately
5
RaymarineMFD,availableseparately
6
RayNetnetworkswitch,availableseparately
7
RayNet-to-RayNetcable,availableseparately
8
RightangledRayNet-to-RayNetcable(3m/9.8ft)(suppliedwithcamera)
9
RJ45–to-RJ45cable,availableseparately
10
PoEinjector(providespowertoJCU-2),availableseparately
11
RayNet-to-RJ45adaptercable,(120mm/4.72in.versionsuppliedwith
camera;otherlengthsavailableseparately)
12
HD-SDIvideocable(BNCconnectors)(3m/9.8ft.)(suppliedwith
camera)
4.7Powerconnection
Powermustbesuppliedtothecamerafromanappropriatepowersource.
Powerconnectionrequirements
•12or24Vdcnominalsupplyvoltage
•Isolatedpowersupply
•Connectedviaanappropriately-ratedthermalbreakerorfusedswitch(refertoInlinefuse
andthermalbreakerratings).
Description
Connectsto:
1
Powercable.Product’spowerconnector.
2
Drain/ground(thinblackwire)
Vessel’sRFground,ornegativebattery
terminal.
Connections59
