FLIR M300C - Single-camera system with web browser and an optional JCU; Single-camera system with digital video (HD-SDI) monitor and JCU

Single-camerasystemwithwebbrowserandanoptionalJCU
Note:Powerconnectionsarenotshowninthisillustration.Thecameraandtheother
devicesshownrequiretheirowndedicatedpowerconnection.
Description
1
M300Seriescamera
2
Joystickcontrolunit(JCU-2),availableseparately
3
Laptop(orotherEthernet-connecteddevicerunningawebbrowser)
4
EthernetnetworkswitchwithPoE
5
RJ45-to-RJ45Ethernetcable
6
RayNet-to-RJ45adaptercable(120mm/4.7in.)(suppliedwithcamera)
7
RightangledRayNet-to-RayNetcable(3m/9.8ft)(suppliedwithcamera)
Single-camerasystemwithdigitalvideo(HD-SDI)monitorandJCU
Forthissystem,adevicerunningawebbrowserisnotrequired.Thecamera’svideofeedis
routedthroughthecamera’sHD-SDIvideoconnectiontoadigitalvideomonitor.Camera
controlisprovidedbyaJCU(availableseparately).
