FLIR M300C - Single-camera system with analog video monitor and JCU

Note:Powerconnectionsarenotshowninthisillustration.Thecameraandtheother
devicesshownrequiretheirowndedicatedpowerconnection.
Description
1
M300Seriescamera
2
Joystickcontrolunit(JCU-2),availableseparately
3
Digitalvideo(HD-SDI)monitor,availableseparatelyfromthird-partyretailers
4
EthernetnetworkswitchwithPoE,availableseparately
5
RayNet-to-RJ45adaptercable(120mm/4.7in.)(suppliedwithcamera)
6
RayNet-to-RayNetcable,availableseparately
7
RJ45–to-RJ45cable,availableseparately
8
HD-SDIvideocable(BNCconnectors)(3m/9.8ft.)(suppliedwith
camera)
9
HD-SDItoHDMIvideoconverter,availableseparatelyfromthird-party
retailers
10
HDMIcable,availableseparatelyfromthird-partyretailers
Single-camerasystemwithanalogvideomonitorandJCU
Forthissystem,adevicerunningawebbrowserisnotrequired.Thecamera’svideofeedis
routedthroughthepowercable’scompositeanalogvideoconnectiontoananalogvideo
monitor.CameracontrolisprovidedbyaJCU(availableseparately).
Connections55
