FLIR M300C - Implementation - direct connection to battery

1
Positive(+)bar
2
Negative(-)bar
3
Circuitbreaker
4
Waterprooffuseholdercontainingasuitably-ratedinlinefusemust
betted.Forsuitablefuserating,referto:In-linefuseandthermal
breakerratings.
Important:
Observetherecommendedfuse/breakerratingsprovidedintheproduct’sdocumentation,
howeverbeawarethatthesuitablefuse/breakerratingisdependentonthenumberof
devicesbeingconnected.
Implementation—directconnectiontobattery
•Whereconnectiontoapowerdistributionpanelisnotpossible,thepowercablesupplied
withyourproductmaybeconnecteddirectlytothevessel'sbattery,viaasuitablyrated
fuseorbreaker.
•ThepowercablesuppliedwithyourproductmayNOTincludeaseparatedrainwire.Ifthis
isthecase,onlythepowercable’sredandblackwiresneedtobeconnected.
•IfthepowercableisNOTsuppliedwithattedinlinefuse,youMUSTtasuitablyrated
fuseorbreakerbetweentheredwireandthebattery’spositiveterminal.
•Refertotheinlinefuseratingsprovidedintheproduct’sdocumentation.
•Ifyouneedtoextendthelengthofthepowercablesuppliedwithyourproduct,ensure
youobservethededicatedPowercableextensionsadviceprovidedintheproduct’s
documentation.
