Connecting a PTZ Camera (M3200 / M4200 SERIES)
23
5. Click Add Preset.
6. Repeat steps 4 and 5 to add additional presets to the tour.
NOTE
Click Del Tour to clear all presets from a tour.
To run a tour:
• Under No., select the number of the tour you would like to go to and click
.
23.2.3 Pattern
Patterns automatically cycle the camera between two positions.
To create a pattern:
1. Click
to open the aux menu.
2. Click the Pattern tab.
3. Under Pattern, enter the pattern you would like to configure.
4. Move the camera into the desired start position and click Begin.
5. Move the camera into the desired end position and click End.
To run a pattern:
• Under No., select the number of the pattern you would like to go to and click
.
23.2.4 Auto Scan
An auto scan automatically cycles between a left and right point.
To create a new auto scan:
1. Click
to open the aux menu.
2. Click the Border tab.
#LX400051; r. 1.0/23100/23101; en-US
163
