FLIR M4416 User Manual

M3200 Series System
Specifications
26
System
Operating System Linux (embedded)
Pentaplex Simultaneous view, record, playback, backup & re-
mote monitoring
Number of Channels 4/8/16 channel — MPX or analog cameras
supported
Inputs/Ouputs
Video IN 4/8/16 x 1Vp-p, CVBS, 75ohms, BNC
BNC Video OUT
No
VGA OUT Yes
HDMI Yes
Audio IN
4 channel, RCA
Audio OUT 1 channel, RCA
USB Port USB 2.0 x 2 (1 at the back, 1 at the front)
Alarm IN 4 ch: 4 Alarm IN, 8 ch: 8 Alarm IN, 16 ch: 16 Alarm
IN
Alarm OUT 3 Alarm OUT
Video Output Resolution 1920x1080 (HDMI), 1280x1024, 1024x768
PTZ Control Via Coax and RS485, supports Pelco D and P
Display
Live Display 4 ch: 1, 4
8 ch: 1, 4, 8
16 ch: 1, 4, 8, 9, 16
Live Display Speed 4 ch: 120 NTSC, 100 PAL
8 ch: 240 NTSC, 200 PAL
16 ch: 480 NTSC, 400 PAL
OSD Camera title, time, video loss, camera lock, motion
detection, recording
System Navigation USB mouse, IR remote controller, front panel
Motion Area Setting Adjustable grid (22x18)
Sensitivity Levels
100
Firmware Upgrade
Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization
Auto time sync by NTP server
Recording
Video Compression H.264
Audio Compression G.711
Recording Resolution NTSC: 1920x1080 (1080p), 1280x720 (720p),
960x480 (960H), 704x480 (D1), CIF (352x240)
PAL: 1920x1080 (1080p), 1280x720 (720p),
960x576 (960H), 704x576 (D1), CIF (352x288)
