FLIR T6xx series

Camera parts
8
8.2 View from the left
8.2.1 Figure
8.2.2 Explanation
1. Lamp for the digital camera.
2. Laser pointer.
3. Lamp for the digital camera.
4. Infrared lens.
5. Digital camera.
Note
The digital camera can be configured to capture digital photos at the same field of view as the infra-
red camera. For more information, see 23 Changing settings, page 61.
6. Focus ring.
7. Button to operate the laser pointer.
