FLIR T6xx series

Handling the camera14
14.5 Adjusting the angle of the lens
14.5.1 Figure
14.6 Adjusting the infrared camera focus manually
14.6.1 Figure
14.6.2 Procedure
Follow this procedure:
1. Do one of the following:
• For far focus, rotate the focus ring clockwise (looking at the touch-screen LCD
side).
• For near focus, rotate the focus ring counter-clockwise (looking at the touch-
screen LCD side).
