Handling the camera14
Note
• Do not touch the lens surface when you adjust the infrared camera focus manually. If this happens,
clean the lens according to the instructions in 27.2 Infrared lens, page 74.
• The focus ring can be rotated infinitely, but only a certain amount of rotation is needed when
focusing.
14.7 Autofocusing the infrared camera
14.7.1 Figure
14.7.2 Procedure
Follow this procedure:
1. To autofocus the camera, push the Autofocus/Save button half-way down.
14.8 Continuous autofocus
14.8.1 General
The camera can be set up to perform a continuous autofocusing sequence. In this mode,
a small frame is displayed on the screen and the camera will continuously autofocus any
object that is within this frame.
14.8.2 Procedure
Follow this procedure:
1. Push
to display the menu system.
2. Use the joystick to go to
(Mode).
3. Push the joystick. This will display a Mode menu.
4. On the Mode menu, select Settings and push the joystick.
5. On the Camera tab, select Continuous auto focus and push the joystick to enable
continuous autofocus.
6. Aim the camera towards the object of interest. The camera will now continuously au-
tofocus any object that is within the small frame in the middle of the screen.
#T559598; r. AB/ 9443/9443; en-US
27
