FLIR T6xx series

Handling the camera14
14.12 Calibrating the compass
14.12.1 Figure
14.12.2 Procedure
Follow this procedure:
1. Push
to display the menu system.
2. Use the joystick to go to
(Mode).
3. Push the joystick. This will display a Mode menu.
4. On the Mode menu, select Settings and push the joystick.
5. Go to the Camera tab.
6. On the Camera tab, select Calibrate compass and push the joystick.
7. Click Start.
8. Calibrate the compass by rotating the camera vertically one revolution and horiston-
tally one revolution.
14.13 Calibrating the touchscreen LCD
14.13.1 Figure
14.13.2 Procedure
Follow this procedure:
1. Push
to display the menu system.
2. Use the joystick to go to
(Mode).
