FLIR Tau User Manual

Appendix A—Pin-out Definitions Tau User’s Manual
A-2 April 2009 TAU-0035-00-10, version 100
Table A-4: I/O Module Digital Data Connector Pin-Out
Pin # Signal Name Signal Definition
1DATA_SYNC+
Digital data sync (LVDS high)
2DATA1_OUT+
Digital data 1 output channel (LVDS high)
3DATA2_OUT+
Digital data 2 output channel (LVDS high)
4DATA_CLK+
Digital output channel clock (LVDS high)
6DATA_SYNC-
Digital data sync (LVDS low)
7DATA1_OUT-
Digital data 1 output channel (LVDS low)
8DATA2_OUT-
Digital data 2 output channel (LVDS low)
9DATA_CLK-
Digital output channel clock (LVDS low)
10 DGND
Digital ground
11 PWR
input power (connected to power connector pin)
12 PWR_RTN
input power return (connected to power connector sleeve)
13 NC
Spare (do not connect)
5,14,15 NC
Spare (do not connect)

FLIR Tau Specifications

General

Thermal Sensitivity (NEdT)	<50 mK
Pixel Size	17μm
Spectral Band	7.5 - 13.5 µm
Frame Rate	Up to 60Hz
Digital Video Output	14-bit digital
Sensor Type	Uncooled microbolometer
Pixel Pitch	17μm
Output Interface	Camera Link
Lens Options	Wide range of lens options available
