TAU-0035-00-10, version 100 April 2009 A-1
Appendix A Pin-out Definitions
A.1 I/O Module 333-0018-00
Camera Connector: See Chapter 5.
Power Connector
: Mates to Switchcraft S760 Miniature Power Plug.
•Video Connector
: Mates to 75Ω BNC twist-on plug.
Serial Connector
: Mates to DB9 Male.
Digital Data Connector
: Mates to Three-Row DB-15 Female.
Table A-1: I/O Module Power Connector Pin-Out
Pin # Signal Name Signal Definition
Pin PWR
input power
Sleeve PWR_RTN
input power return
Table A-2: I/O Module Video Connector Pin-Out
Pin # Signal Name Signal Definition
Pin VIDEO
analog video output
Sleeve VIDEO_RTN
analog video return
Table A-3: I/O Module Serial Connector Pin-Out
Pin # Signal Name Signal Definition
2 RX_232
RS232 Receive channel
3 TX_232
RS232 Transmit channel
5DGND
Digital Ground
1,4, 6-9 NC
Spare (do not connect)
