FLIR Tau User Manual

Tau User’s Manual 1—Introduction
TAU-0035-00-10, version 100 April 2009 1-3
1.2 Available Tau Configurations
The Tau is available with different lenses providing different fields of view and the ‘Slow Video’ or
‘9 Hz’ option for license-free exportability.
Note
Contact FLIR CVS Customer Support or your local FLIR sales representative for information
on available Tau camera configurations, part numbers, and ordering information.
Figure 1-2: Tau Camera as delivered showing 50-pin Hirose Connector and Back Cover

FLIR Tau Specifications

General

Thermal Sensitivity (NEdT)	<50 mK
Pixel Size	17μm
Spectral Band	7.5 - 13.5 µm
Frame Rate	Up to 60Hz
Digital Video Output	14-bit digital
Sensor Type	Uncooled microbolometer
Pixel Pitch	17μm
Output Interface	Camera Link
Lens Options	Wide range of lens options available
