3—Basic Operation of the Tau and GUI Tau User’s Manual
3-14 April 2009 TAU-0035-00-10, version 100
3.9 Analog Video Tab
The Analog Video tab on the FLIR Camera Controller, shown below, provides the ability to
modify four different Tau modes:
• Image Orientation
• Pan & Zoom
•Polarity/LUT
•FFC Warn Time
• Dynamic Digital Detail Enhancement (DDE)
•Video Color
• Video On/Off
Figure 3-6: FLIR Camera Controller Analog Video Tab
1. Select Video
2. Select Analog Video
