FLIR Tau User Manual

TAU-0035-00-10, version 100 April 2009 C-1
Appendix C Mechanical IDD Reference
Due to export restrictions, limited data is available at
www.corebyindigo.com
,
additional data can be obtained from your local sales representative or application engineer.
The following Mechanical Interface Description Documents (IDD) detail the outline and mounting
for the Tau cameras. These documents are provided for reference only. You should consult your
local sales representative or application engineer to obtain current IDD information. Also, the
Tau Thermal Imaging Camera Core Data Sheet available from the website contains important
mechanical interface data as well.
See:
http://www.corebyindigo.com/tau
.

FLIR Tau Specifications

General

Thermal Sensitivity (NEdT)	<50 mK
Pixel Size	17μm
Spectral Band	7.5 - 13.5 µm
Frame Rate	Up to 60Hz
Digital Video Output	14-bit digital
Sensor Type	Uncooled microbolometer
Pixel Pitch	17μm
Output Interface	Camera Link
Lens Options	Wide range of lens options available
