Introduction
218333 04/03/2020
13
1.3 Operating Manual
This operating manual contains information and instructions which shall en-
sure that the operating personnel can work safely, properly and economically
on and with the machine. Only if the contents of the operating manual are un-
derstood and observed, can
Help to avoid hazards
Reduce repair costs and downtime and
Increase the reliability and service life of the machine.
To help you in the use of the operating manual, the sections below provide ex-
planations of systematics and rules used, as well as content and design speci-
fications, and, in some cases, illustrations with an example.
1.3.1 Definition of Terms
This operating manual uses some important terms, which are defined below.
Pillar drilling machine (machine)
The term pillar drilling machine means in this manual the complete machine.
For the sake of simplicity, only the term machine will be used in the following.
Spindle
The term spindle means the rotating component in which the drill chuck with
the cutter can be clamped directly.
Workpiece
The term workpiece means the material in the form of a component to be pro-
cessed.
Cutter
The term Cutter means in this operating manual the machining cutter (drill,
countersink, reamer and tap) used in the machine with which the workpiece is
machined.
Operating company
The operating company is any natural or legal person using the machine or on
whose behalf the machine is used.
Target group
The target group is a specific group of persons for whom specific information
in this operating manual is destined.
