Flott SB 18 Plus - Pillar Drilling Machine Technical Data

Introduction
218333 04/03/2020 7
1.1 Pillar Drilling Machine
1.1.1 Technical Data
Type SB 18 Plus TB 18 Plus TBZ 18 Plus
Order No. 218.308 218.303 218.309
Permanent/normal drilling perfor-
mance
[mm] 18/20
Thread cutting performance [mm] max. M12
Spindle holder Type Mk2
Drilling depth [mm] 100
[mm] a = 240
[mm] b = 82
[mm] c = 340 x 280
Mains voltage [V] 230
Frequency [Hz] 50/60
Motor capacity [kW] 0.75
Stepless spindle speed [rpm] 30-3.000
Weight without packaging [kg] 195 170 155
Weight incl. packaging [kg] 225 200 185
permissible ambient temperature [°C] +10 to +40
Noise emission dB(A) 60
Type SB 20 Plus SB 20 Plus TBZ 20 Plus
Order No. 220.100 220.105 220.110
Order No. SB 20 FB Plus 220.115 --- ---
Permanent/normal drilling perfor-
mance
[mm] 20/23
Thread cutting performance [mm] max. M12
Spindle holder Type Mk2
Drilling depth [mm] 100
[mm] a = 240
[mm] b = 82
[mm] c = 340 x 280
Mains voltage [V] 400
Frequency [Hz] 50/60
Motor capacity [kW] 1.5
Stepless spindle speed [rpm] 40-4.000
Weight without packaging [kg] 195 170 155
Weight incl. packaging [kg] 225 200 185
permissible ambient temperature [°C] +10 to +40
Noise emission dB(A) 60
