Technical Description
218333 04/03/2020
27
3.2 Machine Overview
The following figure shows the individual outer components are shown, which
may be different depending on the machine type.
1 Machine base 8 Drill guard
2 Pillar 9 Spindle
3 Arm / drilling table 10 Lighting / coolant switch
4 Clamping lever 11 Emergency stop button
5 Hand crank 12 Operator panel
6 Toothed rack 13 Protective hood
7 Three-arm-lever 14 Adapter
Machine type: SB 18 Plus
