Introduction
218333 04/03/2020
15
1.3.2 Illustrations and Signs in this Text
To emphasize important information, this manual uses the following picto-
grams, symbols and typographical signs.
Pictograms
General danger
Indicates safety instructions which must be observed and which cannot be
identified with a specific pictogram (e.g. one of the following pictograms).
High electrical voltage
Indicates the risk of electric shock.
Hot parts
Indicates the risk of burns when touching hot machinery and components.
Hand injuries
Indicates the danger of being pulled in, crushed or otherwise injured
Environmentally hazardous substances
Indicates the risk posed by chemical substances if these substances are not
disposed of in accordance with applicable environmental protection laws.
Safety note
Indicates instructions for safe working on and with the machine.
Use ear protection
Use safety goggles
Use safety shoes
Use protective clothing
