Safety Instructions
218333 04/03/2020
25
2.3 Safety Devices of the Machine
For the safety devices on the machine, see the figure in section 3.2 Machine
overview on the page 27.
Protective hood
The protective hood serves as protection against intervention in the rotating
drive unit and the electrical components. The protective hood may only be re-
moved from the machine by qualified personnel for maintenance and repair.
During operation of the machine, the protective hood must be properly mount-
ed.
Drill guard
The height-adjustable drill guard is installed directly in front of the cutter that is
inserted into the spindle and protects the operator from flying swarf.
The drill guard can be swung sideways, which deactivates a protective switch
and the machine cannot be started or stops the rotation. Only when the drill
guard is swung back into its protection position and the protective switch is ac-
tivated, the machine can be started.
Clamping lever of the drilling table
The clamping lever of the drilling table is used to lock or fix the height-
adjustable drilling table. If the drilling table has been moved to the desired ma-
chining height by means of the hand crank, it must be fixed in this position by
the clamping lever.
Emergency stop push-button
You can use the emergency stop button of the control unit, to immediately stop
the motor drive and thus the rotational movement of the spindle in the event of
imminent danger.
The emergency stop button is self-locking. This means you cannot use the
machine until you have eliminated the cause for the interruption and unlocked
the emergency stop button.
