Electrical
Elementary electrical drawings are located in the system manual.
049886-X
Control package
-1 No control package
-2 30 hp Standard 460V 60Hz, 380V 50Hz
-3
30 hp Plus, Premium 460V 60Hz, 380V 50Hz
-4 30 hp Standard 230V 60Hz
-5
30 hp Plus, Premium 230V 60Hz
-10 50 hp Standard 460V 60Hz, 380V 50Hz
-11
50 hp Plus, Premium 460V 60Hz, 380V 50Hz
-12
50 hp Standard 230V 60Hz
-13
50 hp Plus, Premium 230V 60Hz
-50
30 hp or 50 hp Plus (non-B&R-controlled)
-51
30 hp or 50 hp Premium (non-B&R-controlled)
049893-X Cable package
-1
Basic:
30 hp 230V 60Hz, 30 hp 460V 60Hz, 50 hp 460V 60Hz, 50 hp 380V 50Hz
30 hp 380V 50Hz, 30 hp 575V 60Hz, 50 hp 575V 60Hz
-2
On-board:
30 hp 230V 60Hz, 30 hp 460V 60Hz, 50 hp 460V 60Hz, 50 hp 380V 50Hz
30 hp 380V 50Hz, 30 hp 575V 60Hz, 50 hp 575V 60Hz
-3
Remote:
30 hp 230V 60Hz, 30 hp 460V 60Hz, 50 hp 460V 60Hz, 50 hp 380V 50Hz
30 hp 380V 50Hz, 30 hp 575V 60Hz, 50 hp 575V 60Hz
-6
On-board:
50 hp 230V 60Hz
-7
Remote:
50 hp 230V 60Hz
