CHAPTER 5
Engineering Drawings
The following drawings are provided with this manual. Please note that drawings are provided for reference only. Drawings
and part numbers can become obsolete as a part of Flow's ongoing product improvement. If part numbers are replaced by
new numbers, Flow Customer Service will inform you when you order new parts.
30/50 hp HyPlex Prime
050051-X-X-X-X-X HyPlex Prime
049785-X Base unit
-1 30 hp 230V/460V 60Hz
-2 30 hp 380V 50Hz
-6 50 hp 230V/460V 60Hz
-7 50 hp 380V 50Hz
049657-X Hardware kit
-1 Basic package
-2 Standard package
-3
Basic (dual pressure
)
-4
Standard (dual pressure
)
-5
Plus package
-6
Premium package
050242-X Application package
-1 Basic package, no covers
-2 Extended package, covers
-3, -7
With gauge, no covers
-4, -8
With gauge, covers
-5
With transmitter, no covers
-6
With transmitter, covers
