Description
Scope of supply, technical
data and description of the
unit
Scope of supply
The following parts are included in the
basic scope of supply:
Actuator E25 MOD II
These Operating Instructions
The scope of supply may also include
contract-specific, additional docu-
ments, for example:
Operating instructions of the valve
manufacturer
For precise details of the scope of sup-
ply for your unit, please see the delivery
note.
All units can be supplied with a hand
lever as an option.
The unit can be supplied in one of sev-
eral different states.
Unit supplied mounted on a valve
Unit without a valve
When the valve is part of the scope of
supply, it will have been set up already
by the manufacturer.
At the customer’s request the unit can
be supplied packed individually, or
several units can be packed together in
any of the following transport packag-
es:
Transport box
Wire-mesh crate
Pallet
On reception of the delivery, com-
pare the order number on the deliv-
ery note with the details on the
typeplate.
Check that all parts are complete
and in good condition.
Contact the manufacturer without
delay if there are deviations or there
is anything you are not clear about.
Later complaints cannot be accepted.
Technical data
You will find all technical data on the
type plate of the unit and in the data
sheet.
As standard the E25 MOD II is offered
with one of three standard motor volt-
ages:
Motor:
U=110-125 V DC/AC, I=2.1 A, P=130 W
or
U=220 V DC/AC, I=0.95 A, P=130 W
or
three-phase
U=380-440 V 50 Hz / 460-480 V 60 Hz
The motors have internal thermal
switches which break the circuit at
184 °C.
