Flowserve Limitorque LTQ008 - Torque Requirements

LTQ008 – LTQ230 Series 3-Phase Products User Instructions – AIIOM000165 EN
Page 35 of 40
9.2 Torque Requirements
Table 4: Actuator specifications for 3-phase models
Actuator LTQ008 LTQ017 LTQ034 LTQ053 LTQ070 LTQ088 LTQ150 LTQ203
Supply Torque Output (in-lb / N m) 880 / 100 1770 / 200 3540 / 400 5310 / 600 7080 / 800 8850 / 1000 15040 / 1700 20350 / 2300
230/3PH
Current Draw (Start / Run / LRA) 0.7A/0.6A/1.0A 1.8A/1.1A/2.4A 3.6A/1.9A/4.5A
Speed (90°) DC – 60Hz / 50Hz (sec) 16/19 33/39 24/29 33/39 33/39 39/47 28/34 39/47
Motor - 220V Polyphase TENV 40W 90W 200W
On/Off /
Proportional
Duty Cycle (IEC60034)
25% (S2
–
15min) /
75% (S4 – 75%)
25% (S2
-
15 min) /
50% (S4-50%)
Motor Protection, Temp
/
Class
155°C (311ºF) / Class F / 180°C (356ºF) / Class H
155°C / Class F /
180°C / Class H
Motor Starts, per hour, Max All – 600
380/3PH
Current Draw (Start / Run / LRA) 0.4A/0.3A/0.6A 1.1A/0.6A/1.4A 1.6A/0.8A/1.9A 2.1A/1.1A/2.6A
Speed (90°) DC – 60Hz / 50Hz (sec) 16/19 33/39 24/29 33/39 39/47 28/34 39/47
Motor - 380V Polyphase TENV 40W 90W 200W
On/Off /
Proportional
Duty Cycle (IEC60034) 25% (S2 – 15min) / 75% (S4 – 75%) 25% (S2-15 min) / 50% (S4-50%)
Motor Protection, Temp / Class 155°C (311ºF) / Class F / 180°C (356ºF) / Class H 155°C / Class F / 180°C / Class H
Motor Starts, per hour, Max
All
–
600
480/3PH
Current Draw (Start / Run / LRA)
0.2A/0.2A/0.4A 0.7A/0.4A/1.0A 0.9A/0.5A/1.1A 1.2A/0.9A/2.1A
Speed (90°)
–
60Hz / 50Hz (sec)
16 / 19
33 / 39
24 / 29
33 / 39
39 / 47
28 /
34
39 / 47
Motor
-
480V Polyphase TENV
40W
90W
120w
200W
On/Off /
Proportional
Duty Cycle (IEC60034) 25% (S2 – 15 min) / 75% (S4 – 75%) 25% (S2 – 15 min) / 50% (S4 – 50%)
Motor Protection, Temp / Class 155°C (311ºF) / Class F / 180°C (356ºF) / Class H
Motor Starts, per hour, Max All – 600
575/3PH
Current Draw (Start / Run / LRA) 0.2A/0.2A/0.3A 0.4A/0.3A/0.8A 0.8A/0.4A/0.9A 1.0A/0.7A/1.9A
Speed (90°) – 60Hz / 50Hz (sec) 16 / 19 33 / 39 24 / 29 33/ 39 39 / 47 28 / 34 39 / 47
Motor - 575V Polyphase TENV 40W 90W 120W 200W
On/Off /
Proportional
Duty Cycle (IEC60034)
25% (S2
–
15 min) /
75% (S4 – 75%)
25% (S2
–
15 min) /
50% (S4 – 50%)
Motor Protection, Temp / Class
155°C (311ºF) / Class F
Motor Starts, per hour, Max
All
–
600
All
Environmental Rating NEMA 4/4X and IP67
Electrical Entry (2) 3/4” EMT or polyamide gland
Control On/Off, Proportional, in Five Levels of Control and Protection (some limited applications)
Auxiliary Switch – End-of-Travel (4) Form A Volt-Free, Rated 1A @ 24V
Ambient Operating Range -22°F to +158°F (-30°C to +70°C)
Humidity Range 0 – 95% RH
Altitude Limit
9850 ft / 3000 m
