LTQ008 – LTQ230 Series 3-Phase Products User Instructions – AIIOM000165 EN
Page 38 of 40
9.5 Wire Sizing
Wire sizing data is provided in Table below to assist in the selection of the proper wire size for LTQ008 Series
actuators using various wire sizes over distance. Always reference the correct voltage, and do not exceed the
indicated length of the wire run for each model.
Table 5: Maximum distance between actuator and power supply
LTQ008-LTQ017
ACTUATOR
Voltage
230 / 3 380 / 3 480 / 3 575 / 3
Amps
0.7 0.4 0.2 0.2
AWG Maximum Distance – Actuator to Power Supply (ft)
16 1665 10752 25636 33559
14 2649 17102 40774 53375
12 4212 27193 64833 84869
10 6695 43225 103058 134908
8 10650 68761 163940 214606
