Fluke 117 User Manual

True-rms Multimeters
Power-Up Options
9
When you turn the Meter on, it defaults to Autorange and
Auto is displayed.
1. To enter the Manual Range mode, press
q.
Manual is displayed.
2. In the Manual Range mode, press
qto increment
the range. After the highest range, the Meter wraps to
the lowest range.
Note
You cannot manually change the range in the
MIN MAX AVG or Display HOLD modes.
If you press qwhile in MIN MAX AVG or
Display Hold
, the Meter beeps twice, indicating
an invalid operation and the range does not
change.
3. To exit Manual Range, press
q for at least 1 second
or turn the rotary switch. The Meter returns to
Autorange and Auto is displayed.
Power-Up Options
To select a Power-Up Option, hold down the button
indicated in the following table while turning the Meter on.
Power-Up Options are canceled when you turn the Meter
off and when sleep mode is activated.
Button Power-Up Options
f
Turns on all display segments.
p
Disables beeper. bEEP is displayed when
enabled.
q
Enables low impedance capacitance
measurements. LCAP is displayed when
enabled. See page 14.
g
Disables automatic power-down ("Sleep
mode"). PoFF is displayed when enabled.
Q
Disables auto backlight off. LoFF is
displayed when enabled.
Making Basic Measurements
The figures on the following pages show how to make
basic measurements.
When connecting the test leads to the circuit or device,
connect the common (COM) test lead before connecting
the live lead; when removing the test leads, remove the live
lead before removing the common test lead.

Fluke 117 Specifications

General

Diode test	Yes
Product type	Digital multimeter
Product color	Black, Yellow
Measuring category	CAT III 600V
Placement supported	Handheld multimeter
Battery type	9V
Power source	Battery
Battery technology	Alkaline
Number of batteries supported	1
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-10 - 50 °C

Weight and Dimensions

Depth	46 mm
Width	84 mm
Height	167 mm
Weight	550 g
