1
True-rms Multimeters
Introduction
The Fluke Model 114, Model 115, and Model 117 are
battery-powered, true-rms multimeters (hereafter "the
Meter") with a 6000-count display and a bar graph. This
manual applies to all three models. All figures show the
Model 117.
These meters meet CAT III IEC 61010-1 2
nd
Edition
standards. The IEC 61010-1 2
nd
Edition safety standard
defines four measurement categories (CAT I to IV)
based on the magnitude of danger from transient
impulses. CAT III meters are designed to protect
against transients in fixed-equipment installations at the
distribution level.
Contacting Fluke
To contact Fluke, call:
USA: 1-888-99-FLUKE (1-888-993-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore +65-738-5655
Anywhere in the world: +1-425-446-5500
Visit Fluke's web site at www.fluke.com
.
Register your Meter at register.fluke.com
.
Unsafe Voltage
To alert you to the presence of a potentially
hazardous voltage, the Y symbol is displayed when
the Meter measures a voltage ≥30 V or a voltage
overload (OL) condition. When making frequency
measurements >1 kHz, the Y symbol is unspecified.
Test Lead Alert
XWWarning
Personal injury or damage to the
Meter can occur if you attempt to
make a measurement with a lead in an
incorrect terminal.
To remind you to check that the test leads are in the
correct terminals,
LEAd
is briefly displayed and an
audible beep sounds when you move the rotary
switch to
or from any A (Amps) position.
