6.1 Introduction
This chapter contains an illustrated list of replaceable parts for the model 123, 124 or 125
ScopeMeter test tool. Parts are listed by assembly; alphabetized by item number or
reference designator. Each assembly is accompanied by an illustration showing the
location of each part and its item number or reference designator. The parts list gives the
following information:
• Item number or reference designator
• An indication if the part is subject to static discharge: the * symbol
• Description
• Ordering code
• Location on the Main PCA (e.g. ‘C 4 Top’ or ‘B 3 Bottom’ on Top Side or Bottom
Side of PCA).
Caution
A * symbol indicates a device that may be damaged by static
discharge.
6.2 How to Obtain Parts
Contact an authorized Fluke service center.
To locate an authorized service center refer to the second page of this manual (back of the
title page).
In the event that the part ordered has been replaced by a new or improved part, the
replacement will be accompanied by an explanatory note and installation instructions, if
necessary.
To ensure prompt delivery of the correct part, include the following information when
you place an order:
• Instrument model (Fluke 123, 124 or 125), 12 digit instrument code (9444 ... ....), and
serial number (DM.......). The items are printed on the type plate on the bottom
cover.
• Ordering code
• Item number - Reference designator
• Description
• Quantity
6.3 Service Centers
To locate an authorized service center, call Fluke using any of the phone numbers listed
below, or visit on the World Wide Web: www.fluke.com
USA and Canada: 1-888-99-FLUKE (1-888-993-5853)
Europe: +31-40-2675200
Japan: +81-3-3434-0181
Singapore: +65-679 95588
Anywhere in the world: +1-425-446-5500
