Insulation Testers
General Specifications
3
General Specifications
Maximum Voltage Applied to any Terminal ... 600 V ac rms or dc
Storage Temperature........................................ -40 °C to 60 °C (-40 °F to 140 °F)
Operating Temperature .................................... -20 °C to 55 °C (-4 °F to 131 °F)
Temperature Coefficient .................................. 0.05 x (specified accuracy) per °C for temperatures < 18 °C or > 28 °C
(< 64 °F or > 82 °F)
Relative Humidity.............................................. Noncondensing
0 % to 95 % @ 10 °C to 30 °C (50 °F to 86 °F)
0 % to 75 % @ 30 °C to 40 °C (86 °F to 104 °F)
0 % to 40 % @ 40 °C to 55 °C (104 °F to 131 °F)
Vibration ............................................................ Random, 2 g, 5-500 Hz per MIL-PRF-28800F, Class 2 instrument
Shock ................................................................. 1 meter drop per IEC 61010-1 2nd Edition (1 meter drop test, six sides,
oak floor)
Electromagnetic Compatibility........................ In an RF field of 3 V/M, accuracy = specified accuracy (EN 61326-
1:1997).
Safety ................................................................. Complies with ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA-C22.2
NO. 61010-1-04, and IEC/EN 61010-1 2nd Edition for measurement
category IV 600 V (CAT IV)
Certifications ..................................................... CSA per standard CSA/CAN C22.2 No. 61010.1-04; TUV per standard
IEC/EN 61010-1 2nd Edition
Batteries ............................................................ Four AA batteries (NEDA 15A or IEC LR6)
Battery Life ........................................................ Insulation test use: Meter can perform at least 1000 insulation tests
with fresh alkaline batteries at room temperature. These are standard
tests of 1000 V into 1 MΩ with a duty cycle of 5 seconds on and 25
seconds off. Resistance Measurements: Meter can perform at least
2500 earth-bond resistance measurements with fresh alkaline batteries
at room temperature. These are standard tests of 1 Ω with a duty cycle
of 5 seconds on and 25 seconds off.
Size..................................................................... 5.0 cm H x 10.0 cm W x 20.3 cm L (1.97 in H x 3.94 in W x 8.00 in L)
Weight ................................................................ 550 g (1.2 lb.)
IP Rating ............................................................ IP40
Altitude............................................................... Operating: 2000 m CAT IV 600 V, 3000 m CAT III 600 V
Non Operating (Storage): 12,000 m
Over-Range Capability ..................................... 110% of range
Compliance to EN 61557 .................................. IEC61557-1, IEC61557-2, IEC61557-4, IEC61557-10
Model 1503 Accessories .................................. TL224 Leads
TP74 Probes
Clips PN 1958654 (red) and PN 1958646 (black)
Holster
Remote Probe
Model 1507 Accessories .................................. TL224 Leads
TP74 Probes
Clips PN 1958654 (red) and PN 1958646 (black)
Holster
Remote Probe
Model 1508 Accessories .................................. Lead Set PN 666602
Clips PN 1670641 (red) and PN 1670652 (black)
Holster
Remote Probe
