Fluke 150 Series User Manual

Insulation Testers
Service and Parts
31
Service and Parts
User service is limited to replacing parts. Table 10 identifies the replacement parts used
by all models, Tables 11, 12, and 13 identify the replacement parts unique to each model.
Figure 10 shows the location of each part. To order replacement parts refer to Contacting
Fluke earlier in this manual.
MP18
MP16
MP21
MP34
MP10
MP11
MP12-13
(2x)
MP15
MP6
MP1
MP7
H30-32
(3x)
MP32
F1
MP40-43
(4x)
H26-29
(4x)
MP9
MP20
MP22-24
(3x)
MP19
ecz19f.eps
Figure 11. 150X Replacement Parts
