Fluke 1550B User Manual

1550B
Users Manual
16
Following termination of an insulation test the Meter beeps when a
potentially hazardous voltage remains on the test terminals due to
charged-circuit capacitance or from the presence of an external voltage.
4. When the test is terminated, STORE RESULT? is displayed. If appropriate,
store the test results as described in the next procedure. Otherwise,
terminate the STORE RESULT? prompt by pressing the
d button. The
results are not stored.
Storing the Test Results
Upon completion of an insulation test, the Meter displays STORE RESULT? as a
prompt to save the measurement results for future use. The Meter includes
enough memory to store the results of 99 insulation tests for future use.
To store the results of an insulation test use the following procedure:
1. Press
V to save the measurement results. The Meter will assign and
display a sequential tag number (00 to 99) to identify the measurement. If
the tag number is acceptable, press the e button to store the data. If a
different tagging convention is required, proceed as follows to provide a
custom 4-character tag.
a. Notice that an * is blinking on the display. This is the first of the four
characters available for tagging the test results. Repeatedly press the
scroll
R button to cycle through the character positions.
b. At each character position use the V and d buttons to assign a
character (0-9, A-Z).
c. Press the
e button to store the results.

Fluke 1550B Specifications

General

Insulation Test Voltage	250 V, 500 V, 1000 V, 2500 V, 5000 V
Safety Rating	CAT III 1000 V, CAT IV 600 V
Live Circuit Detection	Yes
Guard Terminal	Yes
Operating Temperature	-20°C to 50°C
Storage Temperature	-40°C to 60°C
Display	Digital
Power Supply	12 V rechargeable lead-acid battery
Test Voltage Accuracy	±2%
Automatic Calculation	DAR, PI
