Fluke 1550B User Manual

1
1550B MegOhmMeter
Users Manual
Introduction
The Fluke 1550B MegOhmMeter (hereafter "the Meter") is a high voltage
insulation tester for testing general circuits, including switchgear, motors, and
cables.
The Meter has the following features:
⇒ Large liquid crystal display (LCD) with text display
⇒ Five pre-set test voltage: 250 V, 500 V, 1000 V, 2500 V, and 5000 V
⇒ Programmable test voltage: 250 V to 5000 V (50/100 V steps)
⇒ Resistance measurement: 0 Ω to 1 TΩ
⇒ Polarization Index (PI) measurement
⇒ Dielectric Absorption Ratio (DAR) measurement
⇒ Ramp mode that linearly increases (100 V/s) the applied test voltage
⇒ Test timer and storage for test results with user settable ID tag
⇒ Breakdown voltage indication
⇒ Rechargeable lead-acid battery
⇒ Auto shutoff after 30 minutes of inactivity
⇒ Infrared (IR) port for downloading test data
⇒ PC software supplied
The Meter meets EN 61557 Parts 1 and 2; and EN 61010-1, CAT III 600 V
Pollution Degree 2 standards. CAT III equipment is designed to protect against
transients in equipment in fixed-equipment installations, such as distribution
panels and lighting systems in large buildings.
Contacting Fluke
To contact Fluke for product information, operating assistance, service, or to
get the location of the nearest Fluke distributor or Service Center, call:
1-888-99FLUKE (1-888-993-5853) in U.S.A.
1-800-36-FLUKE (1-800-363-5853) in Canada
+31-402-678-200 in Europe
+81-3-3434-0181 Japan
+65-738-5655 Singapore
+1-425-446-5500 from other countries
Visit Fluke's web site at: www.fluke.com.
Register your Meter at register.fluke.com.

Fluke 1550B Specifications

General

Insulation Test Voltage	250 V, 500 V, 1000 V, 2500 V, 5000 V
Safety Rating	CAT III 1000 V, CAT IV 600 V
Live Circuit Detection	Yes
Guard Terminal	Yes
Operating Temperature	-20°C to 50°C
Storage Temperature	-40°C to 60°C
Display	Digital
Power Supply	12 V rechargeable lead-acid battery
Test Voltage Accuracy	±2%
Automatic Calculation	DAR, PI
