1773/1775/1777
Calibration Manual
10
System Requirements
The system requirements for this verification procedure are:
Windows 10 or Windows 11 32/64-bit (earlier Windows versions below 10 are not tested)
Monitor, 1280 x 1024 (@4:3) or 1440 x 900 (@16:10), wide-screen (16:10) at higher
resolution recommended
USB 2.0 port
RS232 port or USB-to-RS232 converter to control the calibrator (optional)
Microsoft Excel 2010 32/64-bit software or higher (versions below 2010 are not tested)
Fluke Energy Analyze software V3.8 or higher
USB Communication
The verification and adjustment require remote commands to query measurement data and
write commands to set configurations that are not available on the instrument UI. To
communicate between the PC and the instrument, either a USB 2.0 type A to USB-C or USB-C
to USB-C cable can be used. The device driver is included with the Windows operating system.
How to Use the 17xx Calibration Tool
The application, Fluke17xx-CalibrationTool_Vx.x is available at www.fluke.com and
communicates with the instrument using remote commands through the USB ports. The
application also supports the control of the Fluke Calibrators for automated procedures.
The application (Calibration Tool) contains sheets for various tasks:
Dashboard – Live measurements and set current input range/mode
Verification – Procedures to perform the verification
Adjustment – Procedures to perform the adjustment
Setup – Configuration of, for example, the COM ports and resistor values of the voltage
divider
