3 Phase Power Quality Analyzer
Setup
5
Setup
Before you start the verification procedures or make calibration adjustments, refer to this
section for the equipment, system, and setup requirements.
Required Equipment
See Table 2 for a list of requirements for the verification tests and calibration adjustment of the
Product. If the specific equipment is not available, use equivalent equipment that has the same
or better performance.
Table 2. Required Equipment
Item Model Comments
Used for:
Verification Adjustment
Calibrator
5522A with 8588A
Reference DMM
5730A Calibrator, or
equivalent, if 8588A is
not available.
Digital Multimeter (DMM) 8588A or 8846A
Voltage verification/
calibration and AUX
Adapter verification
Cable Assembly 3PHVL-1730
Voltage Test Lead
3-Phase+N
Test Lead Pomona 6358
For voltage PE
connection
17xx AUX Input
Calibration Cable
[1]
NA
17xx Calibration Cables:
Voltage-to-Current Input
Cable Assembly
[1]
NA
17xx Verification Box
[1]
NA
USB Cable USB A-to-USB C
Coil
5500A/COIL
Optional: 52120A
with Coils
for iFlex verification
Coil NA 5 turns
Banana-to-Pin Adapter
Pomona
Electronics 4690
for AUX Adapter
verification
[1] The 173x/174x calibration cables and verification box are not available from Fluke. See Equipment Assembly
for information on how to make these items. The 17xx calibration equipment is identical with the previous
173x/174x equipment.
