3 Phase Power Quality Analyzer
Optional Verification for iFlex or Clamp (Combined Analyzer and Probe Specifications)
21
6. When you are done, set the calibrator to Standby.
Table 14. Clamp Current Probe Input Verification with 52120A Coil
Type/Range
52120A
Range
55x2A
Voltage
Applied
Signal
Upper
Limit
Lower
Limit
i40S-EL, Clamp 40A HIGH 2 A 0.4 V 0.4 A 0.4108 0.3892
i40S-EL, Clamp 40A HIGH 20 A 0.4 V 4 A 4.036 3.964
i40S-EL, Clamp 40A HIGH 120 A 0.4 V 40 A 40.288 39.712
i40S-EL, Clamp 40A LOW 2 A 0.04 V 0.04 A 0.04108 0.03892
i40S-EL, Clamp 40A LOW 2 A 0.4 V 0.4 A 0.4036 0.3964
i40S-EL, Clamp 40A LOW 20 A 0.4 V 4 A 4.0288 3.9712
i17xx-FLEX1.5KIP, Flexi 1500A HIGH
120 A + 3 KA COIL
[1]
0.6 V 1500 A 1515.3 1484.7
i17xx-FLEX1.5KIP, Flexi 1500A HIGH
120 A + 3 KA COIL
[1]
0.32 V 800 A 808.3 791.7
i17xx-FLEX1.5KIP, Flexi 1500A HIGH 120 A 1 V 100 A 101.3 98.7
i17xx-FLEX1.5KIP, Flexi 1500A LOW 120 A 1.1 V 110 A 111.04 108.6
i17xx-FLEX1.5KIP, Flexi 1500A LOW 120 A 0.6 V 60 A 60.9 59.1
i17xx-FLEX1.5KIP, Flexi 1500A LOW 2 A 1 V 1 A 1.04 0.96
i17xx-FLEX3KIP, Flexi 3000A HIGH
120 A + 3 KA COIL
[1]
1 V 2500 A 2525.9 2474.1
i17xx-FLEX3KIP, Flexi 3000A HIGH
120 A + 3 KA COIL
[1]
0.48 V 1200 A 1212.9 1187.1
i17xx-FLEX3KIP, Flexi 3000A HIGH 120 A 1 V 110 A 101.6 98.4
i17xx-FLEX3KIP, Flexi 3000A LOW
120 A + 3 KA COIL
[1]
0.1 V 250 A 253.4 246.6
i17xx-FLEX3KIP, Flexi 3000A LOW 120 A 1.1 V 110 A 112.0 108.0
i17xx-FLEX3KIP, Flexi 3000A LOW 2 A 1 V 1 A 1.07 0.93
i17xx-FLEX6KIP, Flexi 6000A HIGH
120 A + 6 KA COIL
[1]
1.1 V 5500 A 5584.3 5415.7
i17xx-FLEX6KIP, Flexi 6000A HIGH
120 A + 6 KA COIL
[1]
0.5 V 2500 A 2539.3 2460.7
i17xx-FLEX6KIP, Flexi 6000A HIGH 120 A 1 V 100 A 103.3 96.7
i17xx-FLEX6KIP, Flexi 6000A LOW
120 A + 6 KA COIL
[1]
0.11 V 550 A 560.1 540.0
i17xx-FLEX6KIP, Flexi 6000A LOW 120 A 1.1 V 110 A 113.5 106.6
i17xx-FLEX6KIP, Flexi 6000A LOW 2 A 1 V 1 A 1.20 0.80
[1] Steps that use coils are for performance check only due to the low TUR (Test Uncertainty Ratio).
