1773/1775/1777
Users Manual
40
Remote Display. You can remotely connect to the 177x models with a free third-party Virtual
Network Computing (VNC) client available for Windows, Android, Apple iOS, and Windows
Phone after the WiFi connection is set up. VNC allows you to see the screen content, push the
buttons, and touch the targets. Ta b l e 6 is a list of tested VNC clients that work with the
Analyzer.
Complete all the fields in the Configuration screen:
IP Address (for direct connection): 10.237.186.1
When connected to a WiFi Infrastructure: use IP address (see Basic Setup -
Communication Settings)
Port: 5900 (default)
VPN user name and password: are not configured and can be blank.
The remote display mimics the Analyzer screen so you can set up the instrument and view all
the measurements. See Ta b l e 7 . It is not possible to download the data using this connection.
Press any key or tap the display on the Analyzer to disable the remote display and resume
access the Analyzer UI.
Table 6. VNC Clients
Operating System Program Source
Windows 7/8.x/10 TightVNC www.tightvnc.org
Android bVNC Google Play Store
iOS (iPhone, iPad) Mocha VNC Apple App Store
Table 7. Control Keys from VNC Client
Analyzer Key VNC Client Key
W
<cursor right>
X
<cursor left>
Y
<cursor up>
Z
<cursor down>
S <Enter>
B <Esc>
M <F12>
Screen Capture <F11>
