Fluke 52120A - Performance Specifications; Operated Within 6105 A or 6100 B Control Loop, Sine or Harmonic Input (All Current Ranges); Coverage Factor K=2.58 (99 % Confidence Level)

Introduction and Specifications
Performance Specifications 1
1-17
Operating Limits
Output Current Range
2 A 20 A 120 A
Current Output (Max.) 2 A rms 20 A rms 120 A rms
Current Input
Input Current (Max.) 200 mA rms 200 mA rms 120 mA rms
Current gain 10 100 1,000
Voltage Input
Input Voltage (Max.) 2 V rms 2 V rms 1.2 V rms
Transconductance 1 Siemen 10 Siemens 100 Siemens
120 A Range Current/Frequency Limits
Frequency Maximum Output Current Maximum Current Input Maximum Voltage Input
DC
±100 A ±100 mA ±1.0 V
<10 Hz 100 A pk (70 A rms) 100 mA pk (70 mA rms) 1.0 V pk (0.7 V rms)
10 Hz to 10 kHz 170 A pk (120 A rms) 170 mA pk (120 mA rms) 1.7 V pk (1.2 V rms)
Note: The 2 A and 20 A ranges operate at full output current from DC to 10 kHz.
Output Isolation
Frequency Maximum Voltage Signal Applied to any Output Current Terminal with respect to Earth
DC to 850 MHz 600 V rms, 850 V pk, limited 2 A rms, no transient overvoltages
850 Hz to 3 kHz 100 V rms, 142 V pk, limited 2 A rms, no transient overvoltages
3 kHz to 10 kHz 33 V rms, 47 V pk, limited 2 A rms, no transient overvoltages
Performance Specifications
Operated within 6105A or 6100B Control Loop, Sine or Harmonic Input (all current
ranges)
The current and phase angle accuracies of the 52120A when controlled by a single 610X, apply to the parallel output of
up to three 52120As connected as slaves. See the 610X specifications for interharmonic, fluctuating harmonic, dip and
flicker specifications.
Coverage factor k=2.58 (99 % confidence level)
Current Accuracy
Frequency
1-year accuracy, tcal
[1]
±5 °C ±(% of output + % of range)
6105B 6100B
% of output % of range % of output % of range
DC 0.015 0.010 0.022 0.025
10 Hz to 850 Hz 0.011 0.003 0.018 0.003
850 Hz to 6 kHz 0.052 0.005 0.052 0.005
6 kHz to 9 kHz See Operated Stand Alone current accuracy table.
[1] tcal is the temperature at which calibration adjustment took place.
Notes:
Maximum inductance for stability LCOMP OFF is 100 μH. Maximum inductance for stability LCOMP ON is 400 μH for 2 A and 20 A
ranges. 100 μH on the 120 A range.
Phase Angle Accuracy
Frequency Accuracy
10 Hz to 69 Hz
0.006 °
69 Hz to 180 Hz
0.012 °
180 Hz to 450 Hz
0.025 °
450 Hz to 850 Hz
0.045 °
850 Hz to 3 kHz
0.325 °
3 kHz to 6 kHz
0.645 °
