52120A
Users Manual
3-4
Power On and *RST Conditions
All parameters are set to their default values when the Product is energized. Table 3-1 is a
list of items that are set when the Product is turned on and when an *RST command is
received through the GPIB interface. Subsequent changes to these parameters are lost
when you turn off the Product.
Table 3-1. Power On and RST Defaults
Item Power On State *RST State
Input Terminals Voltage Voltage
Range 2A 2A
Output Terminals High High
Load Compensation Off Off
*ESR? 128 Unchanged
*ESE 255 Unchanged
*STB? 32 Unchanged
*SRE 255 Unchanged
:OPER:EVENt 0 Unchanged
:QUES:EVENt 0 Unchanged
SCPI Status Registers
Figure 3-2 shows the relationships of the questionable status register, the event status
register, and the operation status register of the Product.
