Table 5. Controller Communications Commands
Command Description Command Format
Command
Example
Returned
Returned
Example
Acceptable
Values
Display Temperature
Read current set-point s[etpoint] s set: 999.99 {C or F}
set:
150.00 C
-
Set current set-point to n s[etpoint]=n s=200.00 - -
Instrument
Range
Read temperature t[emperature] t t: 999.99 {C or F} t: 55.6 C -
Read temperature units u[nits] u u: x u: C
Set temperature units: u[nits]=c/f - - - C or F
Set temperature units to
Celsius
u[nits]=c u=c - - -
Set temperature units to
Fahrenheit
u[nits]=f u=f - - -
Read scan mode sc[an] sc scan: {ON or OFF} scan:ON -
Set scan mode sc[an]=on/off sc=on - - ON or OFF
Read scan rate sr[ate] sr srat: 99.9 {C or F}/min srat:12.4C/min -
Set scan rate sr[ate]=n sr=1.1 - - .1 to 99.9
Read hold ho[ld] ho
hold: open/closed, 99.9
{C or F}
hold: open, 30.5
C
-
Secondary Menu
Read proportional band
setting
pr[opband] pr pb: 999.9 pb: 15.9 -
Set proportional band to n pr[opband]=n pr=8.83 - -
Depends on
Configuration
Read heater power (duty
cycle)
po[wer] po po: 999.9 po: 1.0 -
Configuration Menu
Operating Parameters Menu
Read stirrer motor speed mo[tor] mo mo: 99 mo: 15 -
Set stirrer motor speed to n mo[tor]=n mo=16 - - 0 to 40
Read high limit hl hl hl:999 hl:126
Set high limit hl=n hl=90 0 to 126
Serial Interface Menu
Read serial sample setting sa[mple] sa sa: 9 sa: 1 -
Set serial sampling setting
to n seconds
sa[mple]=n sa=0 - - 0 to 999
Set serial duplex mode:
du[plex]=f[ull]/
h[alf]
- - - FULL or HALF
Set serial duplex mode to
full
du[plex]=f[ull] du=f - - -
Set serial duplex mode to
half
du[plex]=h[alf] du=h - - -
Set serial linefeed mode: lf[eed]=on/of[f] - - - ON or OFF
Set serial linefeed mode to
on
lf[eed]=on lf=on - - -
Set serial linefeed mode to
off
lf[eed]=of[f] lf=of - - -
