Calibrate a Single Probe
33
Table 5. Controller Communications Command (cont.)
Calibrate a Single Probe
Insert the probe to be calibrated into the well of the bath. For best results insert the probe to the full
depth of the well. Once you insert the probe into the well, allow adequate stabilization time so the test
probe temperature settles as described above. Once the probe has settled to the temperature of the
well, compare that temperature to the displayed calibrator temperature. The display temperature
should be stable to within 0.1 °C (32.18 °F) for best results.
W Caution
Never introduce any foreign material into the well.
Command Description Command Format
Command
Example
Returned
Returned
Example
Acceptable
Values
Calibration Menu
Read R0 calibration
parameter
r[0] r r0: 999.999 r0: 100.578 -
Set R0 calibration
parameter to n
r[0]=n r=100.324 - - 90 to 110
Read ALPHA calibration
parameter
al[pha] al al: 9.9999999 al: 0.0038573 -
Set ALPHA calibration
parameter to n
al[pha]=n al=0.0038433 - - .002 to 005
Read DELTA calibration
parameter
de[lta] de de:9.99999 de: 1.507 -
Read DELTA calibration
parameter
de[lta]=n de=1.3742 - - 0–3.0
Read C0 calibration
parameter
*c[0] *c c0:99.9999 c0:-0.297 -
Set C0 calibration
parameter
*c[0]=n *c=-5.113 - - -
Read CG calibration
parameter
*cg *cg cg:99.999 cg:-0.555 -
Set CG calibration
parameter
*cg=n *cg=-4.115 - -
Functions not on menu
Read firmware version
number
*ver[sion] *ver ver.9999,9.99 ver.7102,2.00 -
Read structure of all
commands
h[elp] h list of commands - -
Read all operating
parameters
all all list of parameters - -
Legend: [] Optional Command data
{} Returns either information
n Numeric data supplied by user
9 Numeric data returned to user
x Character data returned to user
Note: When DUPLEX is set to FULL and a command is sent to READ, the command is returned followed
by a carriage return and linefeed. Then the value is returned as indicated in the RETURNED
column.
