IDA-4 Plus
Operators Manual
2-2
Front Panel Description
1. Liquid Crystal Display-240 dot (W) x 128 (H). Graphic and Alphanumeric. With
backlight.
2. Up, Down, Right and Left key-pad switches
3. Enter keypad.
4. Power ‘ON’ Indicator
5. Channel 1 Fluid ‘IN’ connector.
6. Channel 2 Fluid ‘IN’ connector.
7. Channel 3 Fluid ‘IN’ connector.
8. Channel 4 Fluid ‘IN’ connector.
