Fluke Biomedical IDA-4 Plus - Rear Panel Description

IDA-4 Plus
Operators Manual
2-4
Rear Panel Description
9. Mains ON / OFF switch.
10. Three pin IEC mains inlet connection.
11. Twin fuses integral with mains connector.
12. Alarm Control port. 15 way. (for optional trigger interface).
13. Parallel Printer Port. 25 way Female.
Configured in the same way as a PC Printer Port.
14. Bar Code Wand Port. 9 way Female.
Configured for HP Smart Wand (2400 Baud, n, 8, 1).
15. Computer RS232 Port. 9 way Female.
Configured in the same way as PC COM Port.
16. Channel 4 Fluid ‘OUT’ connector.
17. Channel 3 Fluid ‘OUT’ connector.
18. PC AT keyboard Port.
Configured for AT keyboards.
19. Channel 2 Fluid ‘OUT’ connector.
20. Channel 1 Fluid ‘OUT’ connector.
21. Carrying handle.
