IDA-4 Plus
Operators Manual
3-36
Suggested Apparatus for Back Pressure Testing Drawing
chan nel 1 channel 2
inlets
channel 3 channel 4
3 - WAY TAP
FROM OUTLET CONNECTOR
PRESSURE METER (GAUGE)
FLUID IN FROM INFUSION DEVICE
1 OR 2 LITER BOTTLE
(e.g. MEDICAL SUCTION JAR)
BULB TO PRESSURIZE
BOTTLE
