IDA-4 Plus
Operators Manual
3-6
Start-up Screen
When the unit starts, an introductory screen containing
the name of the instrument, time, date and firmware
version is displayed. After performing initialization
procedures and self tests the instrument advances to the
STATUS ALL CHANNELS screen.
Any errors detected are shown at the bottom of this
screen. Fatal errors are indicated as such and inhibit
progress. Non fatal errors give you the option to
proceed.
Status All Channels Screen
This is a dynamic screen that shows the current activity
on all fitted channels. The designation SETUP indicates
a channel fitted with a transducer and ready for
operation. The upper case designation N/O indicates a
channel that either does not have a transducer fitted, or
is not operational. This is the ‘home screen’; returned to
after all operations except those entered from the
utilities menu.
Moving the cursor to UTIL and pressing ENTER
invokes the UTILITIES menu. Pressing the ENTER
key with the cursor over SETUP invokes the
CHANNEL SETUP menu for the appropriate channel.
The units of pressure displayed on this screen are the
ones selected from the TEST PARAMETERS
SCREEN.
When the screen is first displayed the cursor defaults to
SETUP on the first operational channel. On subsequent
occurrences the cursor should be on the last channel
used. As a test progresses on an active channel the
prompt for that channel changes to reflect the status of
the channel.
When this screen is displayed on subsequent occasions,
channels with operational transducers displays SETUP
if they are not in use, or VIEW if a test is active. Active
channels also show figures relating to the currently
active test.
STATUS ALL CHANNELS
Ch 1 Ch 2 Ch 3 Ch 4
ml / h
T ml
psi
hhmm 00: 00 00: 00 00: 00 00: 00
UTIL SETUP SETUP SETUP SETUP
FLUKE
BIOMEDICAL
IDA-4 Plus
Infusion Device Analyzer
Version 2.09
Serial Num.10001
Date 00-Jan-00 Time 14: 40: 00
