Fluke CertiFiber Pro - How to Use the VFL

CertiFiber Pro Fiber Optical Loss Test Set
Users Manual
90
How to Use the VFL
Figure 28 shows the equipment for tests with the visual fault
locator.
Figure 28. Equipment for Visual Fault Locator Tests
GPU137.EPS
 Versiv main unit with CertiFiber
Pro module installed
 One patch cord to connect the
tester to the fiber (optional)
 Video probe with USB connector
(DI-1000 shown)
 Fiber cleaning supplies
 AC adapter with line cord
(optional)
A
B
C
E
D
